Galvanized Sgce Color Coated Pre Painted Steel Coil Ral 9014 5016

Galvanized Sgce Color Coated Pre Painted Steel Coil Ral 9014 5016

  • Galvanized Sgce Color Coated Pre Painted Steel Coil Ral 9014 5016
  • Galvanized Sgce Color Coated Pre Painted Steel Coil Ral 9014 5016
  • Galvanized Sgce Color Coated Pre Painted Steel Coil Ral 9014 5016
  • Galvanized Sgce Color Coated Pre Painted Steel Coil Ral 9014 5016
Galvanized Sgce Color Coated Pre Painted Steel Coil Ral 9014 5016
Product Details:
Place of Origin: China
Brand Name: RAYMOND
Certification: ISO14000
Payment & Shipping Terms:
Minimum Order Quantity: 50mt
Price: USD500-800/MT
Packaging Details: standard export packing
Delivery Time: 45days
Payment Terms: L/C, T/T, Western Union, MoneyGram, D/A, D/P
Supply Ability: 10000MT/ month
Contact Now
Detailed Product Description
Commodity: Pre-painted Steel Coil Zinc Coating: 150g/㎡
Top Surface: 15 Micron Polyester + 5 Micron Primer Back Surface: 7 Micron + 5 Micron Primer.
Thickness: 0.83mm Width: 1500mm
Color: RAL 7025 Application: Roofing,Structure,Flange Plate,Ship Plate,Container Plate
High Light:

Ral9014 Pre Painted Steel Coil

,

1500mm Color Coated Steel Coil

,

Ral5016 Pre Painted Steel Coil

colour coated steel coils color coated coil colour coated coil prepainted steel coil


PPGI (PPGL) Features:



Product Colored hot dipped galvanized steel in coil
Standard JIS3302, EN 10142, ASTM A653, SGCC/SGCH,European Standard, ASTM A792,
Base plate

Cold rolled steel Coil

Hot dipped galvanized steel coil(small, regular or zero spangle)

Hot dipped galvalume steel coil

Equipment SPCC GALVANIZED STEEL COIL/SHEET Double coating double baking; three coating three painting
Thickness 0.12mm—1.2mm
Width 914mm—1250mm
Zinc Coating 30g-275g/m2
Paint Thickness

Top:15µm-25µm

Back: 5-8µm

Coil Weight 2.5Mt—8Mt
Coil ID φ508mm—φ610mm
Surface paint EP, PE, HDP, SMP, PVDF
Color series RAL color number



MTC of pre painted galvanized steel coil



COMMODITY: PRE-PAINTED ZINC STEEL SHEET Contract NO. HYEXP2010-07-10A Date: SEPTEMBER-17-2010
Steel Grade: ACC JIS G3312, SOFT MATT Condition of Supply PRE-PAINTED ZINC STEEL SHEET
Certificate NO.
100710A
No. Heat No. Size(mm) Zinc Coating: Color side A Coat property Steel property
Pain thick (μm) T-Bend (T) Impact (J) Gloss (GU) Pencil hard YS. Re Mpa UTS. Rm Mpa EL. A %
1 0710225 0.30X800 MM RAL5012 Z-60 RAL 5012/25 microns 25 3 9 50 3H 360 380 35
2 0710296 0.30X800 MM RAL8004 Z-60 RAL 8004/25 microns 25 3 9 55 3H 365 373 37
3 0710246 0.25X800 MM RAL5012 Z-60 RAL 5012/25 microns 25 3 9 50 3H 358 375 36
4 0710288 0.25X800 MM RAL8004 Z-60 RAL 8004/25 microns 25 3 9 55 3H 355 368 36




Application of Pre Painted Aluminum Coil:

1. Construction:roof for steel structure workshop,airport,storeroom

2. Shipbuilding industry

3. Vehicle manufacturing

4. Furniture industry

5. Electric industry etc.



Product Picture



Galvanized Sgce Color Coated Pre Painted Steel Coil Ral 9014 5016 0



Galvanized Sgce Color Coated Pre Painted Steel Coil Ral 9014 5016 1
