１．Product Overview

60g/m² pre painted corrugated roofing sheet is used for roofing, wall cladding, structural use, commercial buildings, household appliance panels, industrial buildings, and general construction applications.

The product is manufactured from color coated galvanized or galvalume steel substrate. The corrugated profile improves sheet rigidity, while the pre painted surface provides decorative appearance and surface protection for roofing and wall systems.

２．Technical Solution

The roofing sheet is produced according to JIS G3322 CGLCC, ASTM A792, and EN 10169 DX51D+AZ standards.

Zinc coating can be supplied at 60g/m², with available coating range from 50g/m² to 180g/m². PE, SMP, PVC, and PVDF painting materials can be selected according to weather exposure, surface appearance, and project requirements.

The 76mm wave width and 17mm wave height provide a common corrugated profile for roofing sheet installation and building cladding applications.

３．Specifications

４．Application

This product is suitable for roofing sheets, wall panels, structural cladding, commercial buildings, industrial workshops, warehouses, container plates, home appliance panels, and general construction projects.

It is commonly used where lightweight corrugated metal panels with color coated surface and galvanized protection are required.

５．Processing

The product supports color coating, corrugating, cutting, profiling, bright or matt finishing, bundling, and export seaworthy packing.

Customized width, length, color, surface finish, painting material, zinc coating, and packing method can be supplied according to project requirements.

６．Advantages

• 60g/m² zinc coating supports basic corrosion protection for common roofing and construction applications.
• 76mm wave width and 17mm wave height improve sheet rigidity and installation stability.
• Color coated surface supports both decorative appearance and surface protection.
• PE, SMP, PVC, and PVDF painting materials are available for different project environments.
• 600mm, 800mm, and 900mm width options support different roofing layouts.
• Export seaworthy packing supports container shipment and long-distance transport.

７．How to Choose

• Choose 60g/m² zinc coating for common building and roofing applications.
• Choose higher zinc coating within 50–180g/m² when stronger corrosion resistance is required.
• Choose PE coating for standard roofing and wall cladding applications.
• Choose SMP or PVDF coating when better weather resistance is required.
• Choose matt finishing for lower-gloss architectural appearance.
• Choose bright finishing for cleaner reflective appearance.
• Confirm thickness, width, zinc coating, paint type, color, surface finish, wave profile, and packing method before production.

８．FAQ

Q1．What is the zinc coating of this product

The highlighted zinc coating is 60g/m², and the available zinc coating range is 50–180g/m².

Q2．What thickness range can be supplied

The available thickness range is 0.14mm to 1.0mm.

Q3．What width options are available

600mm, 800mm, and 900mm widths are available.

Q4．What coating materials can be supplied

PE, SMP, PVC, and PVDF painting materials can be supplied.

Q5．What are the main applications

The product is mainly used for roofing, wall cladding, structural use, commercial buildings, household appliance panels, and industrial construction.
