PPGL 5800mm Pre Painted Steel Sheet DX52D PE 0.25MM Colour Coated Sheet

PPGL 5800mm Pre Painted Steel Sheet DX52D PE 0.25MM Colour Coated Sheet

1. Product Overview

PPGL pre painted steel sheet is used where an aluzinc coated steel base and a finished color surface are both required in one material. This featured specification is positioned around 0.25mm thickness, 1250mm width, and 5800mm length for roofing sheet and wall cladding fabrication.

The product is suitable for projects that require a light gauge painted sheet with practical forming performance, controlled appearance, and direct installation after profiling or panel fabrication.

2. Technical Solution

This product uses a metallic coated steel substrate with an organic paint system on the exposed face. The metallic coating provides the base corrosion barrier, while the PE coating system provides surface color, additional barrier protection, and forming compatibility.

The listed coating structure uses 15–25 micron top coating and 5–7 micron back coating. In practical use, actual outdoor performance depends on the combined effect of metallic coating level, paint build, panel design, drainage condition, cut edge exposure, and installation environment.

For roofing and cladding fabrication, forming quality is important because bend radius, profile depth, and edge stability affect the finished panel more directly than color alone.

3. Specifications

4. Application

• This material is suitable for residential roofing sheets, wall cladding panels, façade sheets, and light building envelope parts.
• It can also be used for profiled sheets, corrugated panels, decorative exterior panels, and other fabricated sheet parts where a finished visible surface is required.
• For house roofing applications, it is more suitable when the panel profile, slope design, and overlap detail are matched to the local weather condition.

5. Processing

• The sheet can be supplied for direct cut sheet use or for downstream profiling and forming.
• It is suitable for roll forming, bending, shearing, and general sheet metal fabrication.
• For deeper profiles or tighter bends, the selected forming quality and coating system should be matched to the production route so the visible surface remains stable after profiling.

6. Advantages

• The 0.25mm and 1250mm configuration is suitable for light gauge roofing and cladding conversion.
• The PE coating system provides a practical balance between appearance and standard exterior use.
• The Z40–150g/m2 metallic coating range allows the sheet to be matched to different project conditions.
• The available surface options support both functional and decorative applications.
• The 5800mm cut length is suitable for longer roof and wall panel layouts with fewer joints.

7. How to Choose

• Choose 0.25mm when the project needs a light sheet for economical profiling and panel production.
• Choose 1250mm width when the downstream line is configured for that blank width or effective coverage target.
• Choose the metallic coating level according to the service environment and corrosion protection target.
• Choose matt, gloss, wrinkle, wood grain, or marble surface according to the final design requirement.
• Choose the final color according to the project appearance target and roof heat management consideration.

8. FAQ

Q1. Is this product PPGL or PPGI
This page is positioned as PPGL pre painted steel sheet.

Q2. What is the featured size on this page
The featured size is 0.25mm thickness, 1250mm width, and 5800mm length.

Q3. What metallic coating range is available
The listed metallic coating range is Z40–150g/m2.

Q4. Can the color be customized
Yes. The product can be supplied in RAL colors or customized color according to project requirement.

Q5. Is this product suitable for roofing and wall cladding
Yes. It is suitable for roofing sheets, wall cladding panels, and related exterior building sheet applications.
